Name: ABB SYN5302A-Z,V217 3BHB006716R0217 | ABB Converter Pulse Sync Interface Board - ABB DCS HEAVY EQUIPMENT
SKU: ABB SYN5302A-Z,V217 3BHB006716R0217
Price: 16520.00 USD
Availability: InStock

Description

Meta Description

ABB SYN5302A-Z,V217 (3BHB006716R0217) is a pulse synchronization control board used in ABB medium voltage converter systems. It manages pulse signal alignment between power stacks to ensure stable parallel operation. New surplus available, every unit undergoes complete function testing prior to delivery.

Product Core Brief

Model: SYN5302A-Z,V217 (3BHB006716R0217)
Brand: ABB
Series: Medium Voltage Converter Control Boards
Core Function: Realize pulse synchronization for multi-stack power converter units
Type: Pulse Synchronization Control Board
Key Specs: Hardware Revision V217, multi-channel pulse signal processing
Condition: New Surplus, non-refurbished

⚠️ Original production discontinued, stock availability limited

Product Introduction

Unmatched pulse timing between parallel power stacks easily triggers overcurrent trips during converter operation, and this board solves that critical issue. The SYN5302A-Z,V217 3BHB006716R0217 receives reference signals and distributes synchronized drive pulses across multiple power modules inside medium voltage converters.

Its built-in signal filtering improves resistance against on-site electromagnetic noise. Consistent pulse phase alignment lowers circulating current when power stacks work in parallel. This board is widely deployed in heavy-industry MV drives, static frequency conversion and power quality control equipment.

Key Technical Specifications

Parameter	Value
Full Part Number	SYN5302A-Z,V217 / 3BHB006716R0217
Hardware Revision	V217
Main Function	Pulse synchronization control for parallel power stacks
Signal Type	Low-level control pulse signals
Operating Temperature	0 °C ~ +60 °C
Mounting Form	Cabinet backplane installation
Application Range	ABB medium voltage converter systems
Protection Circuit	Onboard signal filtering and surge suppression

ABB SYN5302A-Z,V217 3BHB006716R0217

Quality Control Testing Procedure

Incoming Inspection & Trace Verification

Verify serial numbers and factory label integrity. Complete visual inspection to check for PCB scratches, component discoloration, solder repair traces and corrosion. All original labels are cross-checked and recorded.
Live Functional Bench Test

Install the board on a dedicated converter simulation rack. Execute power-on self-test, signal input/output verification and continuous synchronization stability testing. Test photos and records can be provided on request.
Electrical Parameter Measurement

Use Fluke test instruments to conduct continuity testing and insulation resistance inspection. Confirm no hidden short-circuit risks on circuit traces.
Hardware Configuration Record

Document hardware revision V217. Capture photos of onboard jumpers and DIP switch positions for reference during field commissioning.
Final QC & Packing

Qualified boards are sealed in anti-static bags, wrapped with bubble film and packed into rigid export cartons. Each unit carries a signed QC Passed label with test date.

Field Installation Pitfall Guide

❗ Hardware revision mismatch leads to synchronization failure.

We have seen maintenance teams install boards with different revisions. Even if the base model number matches, differing V-revisions alter internal signal logic and cause unstable pulse alignment. Always record the revision code V217 from the faulty board before ordering.

❗ Improper wiring distorts synchronization signals.

Route pulse signal cables separately from high-power wiring. Crosstalk will shift pulse timing and increase circulating current between power stacks. Follow the official wiring diagram strictly.

❗ Reset jumper settings after replacement.

Factory default jumper positions may not match site configuration. Take clear photos of the original board’s jumpers before removal to avoid commissioning delays.

❗ ESD protection is mandatory during handling.

Surface-mount components on this PCB are sensitive to static electricity. Wear anti-static wristbands and operate on an anti-static mat, especially in dry seasons.

Quick Conclusions

SYN5302A-Z,V217 3BHB006716R0217 serves as the pulse synchronization board for ABB medium voltage converters.
Hardware revision V217 must be confirmed; mismatched revisions risk abnormal operation.
The board suppresses circulating current by maintaining accurate pulse alignment for parallel power stacks.
Original manufacturing discontinued; inventory consists of limited new surplus stock.
Full pre-shipment bench testing and supporting test documentation are available.
