Name: ABB CC-U/STD 1SVR040000R1700 | New Original Industrial Signal Converter In Stock Fast Shipping - ABB DCS HEAVY EQUIPMENT
SKU: ABB CC-U/STD 1SVR040000R1700
Price: 3789.00 USD
Availability: InStock

Description

Product Core Brief

Model: 1SVR040000R1700 (CC-U/STD)
Brand: ABB
Series: 300 Series Signal Conditioning Modules
Core Function: Converts and isolates diverse industrial analog and temperature signals for control system compatibility
Type: Universal Isolated Signal Converter
Key Specs: 3-way galvanic isolation; 0.1% full-scale accuracy; short-circuit proof output
Condition: New Original, factory sealed, non-refurbished

Product Introduction

Mismatched signal types and ground loop interference often cause unstable data reading in process automation systems. The ABB 1SVR040000R1700 is a universal signal conversion unit built for standard industrial signal processing. It unifies disparate sensor signals into standard analog outputs for PLC and SCADA systems.

This module supports configurable voltage, current, RTD and thermocouple input types, covering most factory temperature and analog measurement scenarios. It delivers 3-way electrical isolation between input, output and power terminals to eliminate ground loop noise. With max 500 mW low power consumption and wide temperature adaptability, it maintains consistent precision in crowded electrical cabinets. Field technicians favor this unit for its flexible on-site tuning and zero complex software configuration.

Key Technical Specifications

Parameter Item	Technical Data
Part Number	1SVR040000R1700 (CC-U/STD)
Device Type	Universal Isolated Signal Converter
Input Signals	4-20 mA, 0-10 V, PT100 RTD, J/K Thermocouple
Output Signals	Configurable 4-20 mA / 0-10 V DC
Isolation Mode	3-way galvanic isolation (Input / Output / Power)
Conversion Accuracy	±0.1% full scale
Power Supply	24–48 V DC
Power Consumption	Max 500 mW
Protection Feature	Short-circuit resistant signal output
Mounting Method	Standard DIN rail mounting
Operating Temperature	-20°C to +60°C
Dimension	22.5 mm × 105 mm × 120 mm
Configuration	Front panel manual adjustment, no software required

ABB CC-U/STD 1SVR040000R1700

Installation & Configuration Guide

Stage 1: Pre-Installation Preparation (8 mins)

Notify field maintenance personnel to suspend related measurement loops. Cut off 24–48 V DC power for the signal converter loop. Wait 3 minutes for circuit residual discharge.

Prepare tools: ESD wrist strap, PH1 screwdriver, digital multimeter and mobile phone for configuration recording. Confirm field signal types (temperature or analog) to match module setup parameters.

Stage 2: Old Module Removal (10 mins)

Mark input, output and power cables clearly before disconnection. Release DIN rail buckle and slide out the old converter. Clean the rail surface and terminal dust with dry cloth. Check for cable aging or oxidation that may affect signal stability.

Stage 3: New Module Installation (12 mins)

Wear anti-static gear before unpacking the ABB 1SVR040000R1700 unit. Slide the module firmly onto standard DIN rail until locked.

Restore wiring strictly by terminal definitions: power to dedicated supply terminals, field sensor signals to input ports, control system cables to output ports.

Replicate original signal range settings via front panel adjustment knobs. Double-check no reversed wiring or loose terminals.

Pre-power-on self-check: Confirm locked rail installation, correct signal direction and no short-circuit risks.

Stage 4: Power-On & Calibration (20 mins)

Restore DC power supply and check power indicator status. Select matching input mode (RTD / TC / analog) via front panel dials.

Perform zero-point calibration with no-load input. Apply standard signal source for full-scale trimming to ensure 0.1% precision.

Verify upper system receives stable, linear signal feedback. Run 30 minutes continuous monitoring with no signal drift or alarms to finish commissioning.

Frequently Asked Questions (FAQ)

1. What signal types can the 1SVR040000R1700 process?

It handles standard current/voltage analog signals and common temperature signals. Supported types include 4-20 mA, 0-10 V, PT100 RTD, and J/K type thermocouples, covering most process industry measurement needs.

2. Why does this module use 3-way isolation design?

Three-way isolation separates input field side, output control side and power supply side. It effectively blocks ground loop interference and high-frequency noise, a must for stable long-distance signal transmission in industrial sites.

3. Can I adjust parameters without professional software?

Yes. All configuration and calibration rely on front panel physical dials. No engineering software or communication cables are needed, which speeds up on-site commissioning significantly.

4. What causes fluctuating output signals after replacement?

Most instability comes from uncalibrated zero/full scale values or poor grounding. Re-calibrate the module and confirm single-point system grounding. Damaged field sensor cables can also trigger signal jitter.

5. Is hot-swap replacement allowed on live loops?

Not recommended. Live plugging may generate instantaneous voltage spikes and damage internal isolation circuits. Always cut local power before replacement.

6. What is the warranty and testing standard?

We provide 12-month warranty. Every unit undergoes full signal accuracy testing and short-circuit protection verification before delivery. Test records are available upon request.
