GE DS200LDCCH1AKA | Genuine OEM Speedtronic DCS Spare Part

Product Core Brief

Model: DS200LDCCH1AKA
Brand: GE General Electric (GE Vernova)
Series: Speedtronic Mark V Turbine Control System
Core Function: Drive control and LAN communication between Mark V controller, drives and exciter units
Type: LDCC Drive Control LAN Communications Board
Key Specs: 4 independent onboard microprocessors | Flash PROM configuration storage | Mark V backplane bus interface
Condition Note: New Surplus, non-refurbished

⚠️ Mark V platform is legacy hardware. OEM lead times are extended, spare inventories are limited globally.

Key Technical Specifications

Parameter	Details
Full Part Number	DS200LDCCH1AKA
Functional Name	LDCC Drive Control LAN Communications Board
Compatible System	GE Speedtronic Mark V, DIRECTO-MATIC 2000 Drives & Exciters
Onboard Processors	Four dedicated microprocessors (LAN, drive, motor, co-motor control)
Configuration Storage	Multiple flash PROM chips for firmware and parameter archive
Interface	Proprietary Mark V rack backplane connectors; operator interface port
PCB Protection	Conformal coated circuit board for anti-corrosion
Operating Temperature	-20 °C ~ +65 °C
Relative Humidity	5% ~ 95% RH, non-condensing
Mechanical Form	Standard Mark V rack plug-in PCB board
Reference Manual	GEI-100216
Protection Class	IP20 (indoor control cabinet installation)

GE DS200LDCCH1AKA

Product Introduction

GE DS200LDCCH1AKA is a core LDCC communications board for the GE Speedtronic Mark V turbine control system. It acts as the intermediate data bridge between the main turbine controller, excitation systems and drive assemblies.

Four independent microprocessors handle LAN data exchange, drive logic processing, motor control and system reset functions simultaneously. All configuration parameters are stored in onboard flash PROM. The conformal coating improves stability in cabinet environments with humidity and light chemical contamination. This board is critical for gas turbine, steam turbine and generator excitation control racks.

Application Scenarios & Pain Points

Power plant operators know that a faulty LDCC communication board will break data exchange between the turbine controller and excitation drive. Loss of communication triggers turbine protection logic, leading to unplanned unit shutdown and massive economic losses. Most power stations maintain spare DS200LDCCH1AKA to shorten emergency maintenance duration.

Typical Application Scenarios:

Combined Cycle Power Plants – Gas Turbine Mark V Control Cabinets

Serve as communication interface for generator excitation control, speed regulation and load demand control.
Thermal Power Plants – Steam Turbine Auxiliary Drive Control

Manage communication between main controller and boiler feed pump variable speed drives.
Oil & Gas Refineries – Gas Turbine Driven Compressor Units

Continuous control of mechanical drive turbines under variable load process conditions.
Cogeneration Facilities – Reciprocating Engine & Turbine Generator Sets

Balance plant load control and generator excitation signal transmission.
Industrial Energy Plants – Waste Heat Recovery Turbine Control

Stable long-term operation under fluctuating process heat conditions.

Onsite Case Reference

Last quarter, a 250MW combined-cycle power plant received continuous communication fault alarms on its Mark V turbine rack. Troubleshooting confirmed failure of the DS200LDCCH1AKA board.

GE official delivery lead time reached 11 weeks. Running the gas turbine without complete excitation communication protection was prohibited by plant safety regulations.

Our stocked DS200LDCCH1AKA completed full bench testing and shipped within 3 working days. Maintenance engineers replaced the board during planned shutdown, loaded matched firmware and configuration. All communication links recovered immediately after power-on. The plant added two identical boards to critical spare inventory afterwards.

Compatibility & Replacement Matrix

DS200LDCCH1AKA → DS200LDCCH1AKA : Direct replacement. Verify hardware revision and firmware version before installation.

DS200LDCCH1AKA → DS200LDCCH1AGA / DS200LDCCH1ANA : Pin compatible, but firmware and hardware revisions differ; requires full parameter re-verification, not plug-and-play.

DS200LDCCH1AKA → Mark VI / Mark VIe series boards : Hardware architecture mismatch, completely incompatible.

⚠️ Important reminder: Photograph jumper positions and record existing firmware revision from the faulty board before purchasing. Mismatched firmware will cause communication failure.

GE DS200LDCCH1AKA

Quality Control Procedure (Transparent Testing Standard)

Incoming Inspection

Serial number and nameplate verification. Visual inspection for PCB scratches, corrosion, disassembly traces and connector damage. Check conformal coating integrity.
Bench Functional Live Test

Test platform: Complete GE Mark V simulation rack with controller and drive simulator.

Test items: Power-on initialization, backplane bus communication test, processor self-test, continuous 24-hour ageing test. Formal test report available upon request.
Electrical Parameter Test

Bus signal waveform verification, insulation resistance test, connector continuity test.
Hardware Archive

Record board hardware revision; photograph jumper layout and PROM component layout for file storage.
Final QC & Packaging

Inspector signature confirmation. Sealed inside anti-static bag, wrapped with bubble film and export carton. Attached QC Passed label with testing date. Testing photos or video can be provided to clients.
